Brief Introduction

ST-REL3-KG 24/21AU

Product type: Relay module, equipped with miniature switch relay, belongs to the plug-in relay.Electrical characteristicsInput data: Rated input voltage is 24V AC/DC with input voltage range of 19.2V AC/DC to 26.4V AC/DC AT 20°C. The drive mode is monostable and polarized, with a typical input current of 21mA, a typical response time of 7ms, and a typical release time of 11ms (at DC) at the rated input voltage. The protection circuit is a bridge rectifier, a varistor, and a working voltage indicator (LED indicator).Output data: 1 changeover contact (1PDT) for contact switching, single contact type for switching, AgNi contact material. The maximum switching voltage is 250V AC/DC, the limited continuous current is 6A, the maximum inrush current is 8A, and the open circuit rating (resistive load) is up to 95W (at 24V DC), 50W (at 48V DC), 45W (at 60V DC), 35W (at 110V DC), 55W (at 220V DC), 1500VA (at 250V AC).
