Brief Introduction

MDX61B0011-5A3-4-00

Rated power: 1.1kW.Input parameters: rated voltage is three-phase AC 380 - 500V, power supply frequency 50 - 60Hz, input current 2.8A.Output parameters: output capacity 2.1kVA, output current 3.1A, output frequency range is usually 0 - 400Hz.Overload capacity: 150% overload operation for 60s, 200% short-time overload for 1s (for power of 1.5kW and below).Degree of protection: IP20, suitable for indoor cleaning environment, can prevent the intrusion of solid objects larger than 12mm.Dimensions: Width 9.5cm, height 31.7cm, depth 26cm.Weight: 2.8kg.Control functionsControl mode: Support voltage vector control (VFC), current vector control (CFC) and other control methods, which can realize high-precision control of the motor.Built-in functions: Integrated IPOS positioning and sequence control system, which can easily realize speed control, single-axis position control and other functions, and can also complete driving tasks such as positioning and curling through standardized control programs, and users can set parameters through wizards without complex programming.
