Brief Introduction

MDX61B-0370-503-4-00

Basic parametersRated power: 37kW.Input parameters: three-phase AC 380 - 500V, power supply frequency 50 - 60Hz, input current 65.7A.Output parameters: output capacity 51.1kVA, output current 73A, output frequency range 0 - 599Hz (can be adjusted according to settings).Overload capacity: 150% overload allowed for 60s, 175% overload allowed for 2s.Degree of protection: IP20.Dimensions: Width 28cm, height 52cm, depth 30.7cm.Weight: 27kg.Control functionsControl mode: Support voltage vector control (VFC), current vector control (CFC), etc., to achieve high-precision control of the motor.Built-in functions: Integrated IPOS positioning and sequence control system for speed control, single-axis position control, and more. Drive tasks such as positioning and curling can be completed through standardized control programs, and the user can use the wizard to set the parameters without complex programming.
