As of November 23, 2023
Specifications and design of the products are subject to change without notice for the product improvement.
Spec Detail
| Item | Specifications |
|---|---|
| Product Number | FD-L10 |
| Part Number | FD-L10 |
| Sensing mode | Convergent Reflective type |
| Fiber type | Glass substrate detection |
| Fiber head length | W12 x H19 x D3 mm |
| With sleeve | No |
| Beam direction | Top-view |
| Fiber cable length | 2 m |
| Allowable bending radius | R4 mm |
| Free-cut | Available |
| Semi-custom | Fiber length change |
| Mounting lens | Not available |
| Mounting protective tube | Not available |
| Application | Glass substrate detection Seating confirmation |
| Environmental resistance : Protection | IP40 |
| Environmental resistance : Ambient temperature MAX | 60 degrees |
| Environmental resistance : Ambient temperature MIN | -40 degrees |
| Sensing range（STD） | 0 to 5 mm 0 to 0.197 in (FX-500 series) |
| Sensing range（HYPR） | 0 to 6 mm 0 to 0.236 in (FX-500 series) |
| Sensing range（U-LG） | 0 to 5.5 mm 0 to 0.217 in (FX-500 series) |
| Sensing range（LONG） | 0 to 5.5 mm 0 to 0.217 in (FX-500 series) |
| Sensing range（FAST） | 0 to 4.5 mm 0 to 0.177 in (FX-500 series) |
| Sensing range（H-SP） | 0 to 4 mm 0 to 0.157 in (FX-500 series) |
